Through Feed CNC Door Four-Side Cutter With Scoring Saw And Main Saw

    Buy cheap Through Feed CNC Door Four-Side Cutter With Scoring Saw And Main Saw from wholesalers

    Buy cheap Through Feed CNC Door Four-Side Cutter With Scoring Saw And Main Saw from wholesalers
    • Buy cheap Through Feed CNC Door Four-Side Cutter With Scoring Saw And Main Saw from wholesalers
    • Buy cheap Through Feed CNC Door Four-Side Cutter With Scoring Saw And Main Saw from wholesalers
    • Buy cheap Through Feed CNC Door Four-Side Cutter With Scoring Saw And Main Saw from wholesalers

    Through Feed CNC Door Four-Side Cutter With Scoring Saw And Main Saw

    Ask Lasest Price
    Brand Name : HOLD
    Model Number : HV321
    Certification : CE
    Price : Negotiable
    Payment Terms : LC/ TT
    Supply Ability : 10 Set / Month
    Delivery Time : 45 Days
    • Product Details
    • Company Profile

    Through Feed CNC Door Four-Side Cutter With Scoring Saw And Main Saw

    Through Feed CNC Door Four-Side Cutter With Scoring Saw And Main Saw - HV321


    Features


    • Suitable for all kinds of wooden door 4-sided cutting.
    • Through-type feeding and unloading. Suitable for single machine and connection operation.
    • One door squaring needs only 50s for fastest.
    • One set of horizontal saw + two sets of vertical saw
    • With scoring saw to avoid cracking
    • With precise clamping positioning and middle positioning
    • With waste material collecting belt
    • Servo motor to adjust width automatically

    Base information

    ModelHV321
    Max. working length2700mmWorking width300-1200mm
    Working thickness30-60mmFastest cutting speed18m/min
    Main saw spindle speed3000rpmScoring saw spindle speed12000rpm
    Main saw motor power5.8kw

    Scoring saw motor

    power

    2.2kw
    Main saw specΦ30xΦ300mmScoring saw specΦ22xΦ120mm
    Total powerAbout 36kwMachine size

    About

    4670x2750x3100mm


    Waste collecting belt:


    Through Feed CNC Door Four-Side Cutter With Scoring Saw And Main Saw


    Main saw + scoring saw:


    Through Feed CNC Door Four-Side Cutter With Scoring Saw And Main Saw


    Automatically adjusted scoring saw:


    Through Feed CNC Door Four-Side Cutter With Scoring Saw And Main Saw


    About our company

    One-stop solution for interior furniture equipment and wooden door equipment

    HOLD Machinery was founded in 2004, focusing on the development of a full range of furniture machinery equipment and wooden door machinery and equipment, providing furniture and wooden door enterprises with solutions for whole factory planning and automatical production lines, providing customers with excellent quality, efficient and stable products, and high-quality service.

    HOLD Machinery has served the majority of furniture and wooden door enterprises in more than 40 countries and regions around the world and has won wide admiration from customers.


    FAQ:

    1. Do you have the machine in stock?
    Sorry, we don't have the machine in stock, edge banding machine has many options such as voltage, speed, function, and so on, So it's hard to prepared samples.

    2. How long is your delivery time?
    For our standard model, the delivery time is around 1.5~2 months. For the customized model, the delivery time is around 2~3 months. It depends on the client's project and quantity.

    3. Do you have a factory?
    Yes, we have our own factory and we promise direct sales at a competitive price. Welcome to visit our factory at any time.
