Woodworking Edge Banding Machine with belt presser beam HD836JPUKQLL

Edge bander with belt pressing beam conveyor, specially designed for high-gloss panel, skin-feel panel, and acrylic edge banding. In now-days, more and more customers request very high-quality products such as high gloss panel kitchen cabinets / Fullhouse customize wardrobes/ etc.

1. Upper gluing pot gluing system, equipped with PUR melter (U) and EVA fast melter (K) + automatic glue plastic storage and pump

(Q). One-pot for two kinds of glue: PUR and EVA fast switching.

2. Heavy-duty base: It has strong rigidity and anti-deformation ability. It is annealed and finely processed to greatly reduce frame deformation and improve the stability of operation and long-term use.

3. Belt presses material. The workpiece is stable without indentation, and the sticking effect is perfect.

4. Electric lifting press beam reduces labor intensity and improves efficiency and accuracy.

5. Six-pressing roller and scraping device: it removes excess hot melt glue from the board quickly.

6. There are rough trimming, two-profile fine trimming, and scraping. Two different thickness edges can be set, which can easily switch between thick and thin edge banding with one button to solve the trouble of knife adjustment.

7. Diamond trimming saw blade has a longer service life.

8. Two Horizontal grooving units, dedicated for the door frame.

9. Continuous reciprocating polishing can prolong the service life of the polishing cloth wheel.

10. Conveyor reducer adopts a high-efficiency harden gear motor, which is powerful.

Technical Parameters

Video for more detail about our machines and company.

About our company

One-stop solution for interior furniture equipment and wooden door equipment

HOLD Machinery was founded in 2004, focusing on the development of a full range of furniture machinery equipment and wooden door machinery and equipment, providing furniture and wooden door enterprises with solutions for whole factory planning and automatical production lines, providing customers with excellent quality, efficient and stable products, and high-quality service.

HOLD Machinery has served the majority of furniture and wooden door enterprises in more than 40 countries and regions around the world and has won wide admiration from customers.

FAQ:

1. Do you have the machine in stock?
Sorry, we don't have the machine in stock, edge banding machine has many options such as voltage, speed, function, and so on, So it's hard to prepared samples.

2. How long is your delivery time?
For our standard model, the delivery time is around 1.5~2 months. For the customized model, the delivery time is around 2~3 months. It depends on the client's project and quantity.

3. Do you have a factory?
Yes, we have our own factory and we promise direct sales at a competitive price. Welcome to visit our factory at any time.
