45 Degree Bevel Edge Banding Machine HD781JDPKQ
Features:
1. One machine for two functions --straight edge banding &bevel
edge banding, one-button switch.
2. The beveled edge is usually applied to cabinet door panels instead
of using the hardware, it can save some cost and also make the
cabinets look nicer.
3. Machine is equipped with two glue pots, one is underneath gluing
pot, another one is up gluing pot, the up gluing pot can work with
the PUR glue.
4. Pre-milling device for the up glue pot, easy to add the glue.
5. High configuration for straight edge banding.
More Details:
Quick Detail
| Model | HD781JDPKQ |
| Banding tape thickness | ST0.4~3(mm)/BL0.4~1.5(mm) |
| Banding tape width | 12-65mm |
| Workpiece thickness | ST10~60(mm)BL10~25(mm) |
| Workpiece length | >=100mm |
| Workpiece width | >=80mm |
| Heating power | 1.8kw |
| Feeding motor power | 4.0kw |
| Glue spreading motor power | 0.75kw |
| End trimming motor power | 0.5kw*2 |
| Rough trimming motor power | 0.75kw*2 |
| Fine trimming motor power | 0.75kw*2 |
| Corner rounding motor power | 0.5kw*2 |
| Polishing motor power | 0.37kw*2 |
| Feeding speed | 12-20-23(m/Min) |
| Air pressure | 0.6Mpa |
| Overall dimension | 10610mm*900mm*1800mm |
If you want to know more about this machine, please don't hesitate
to contact me, more detail and products , please click the below
link.
About our company
One-stop solution for interior furniture equipment and wooden door
equipment
HOLD Machinery was founded in 2004, focusing on the development of
a full range of furniture machinery equipment and wooden door
machinery and equipment, providing furniture and wooden door
enterprises with solutions for whole factory planning and
automatical production lines, providing customers with excellent
quality, efficient and stable products, and high-quality service.
HOLD Machinery has served the majority of furniture and wooden door
enterprises in more than 40 countries and regions around the world
and has won wide admiration from customers.
FAQ:
1. Do you have the machine in stock?
Sorry, we don't have the machine in stock, edge banding machine has
many options such as voltage, speed, function, and so on, So it's
hard to prepared samples.
2. How long is your delivery time?
For our standard model, the delivery time is around 1.5~2 months.
For the customized model, the delivery time is around 2~3 months.
It depends on the client's project and quantity.
3. Do you have a factory?
Yes, we have our own factory and we promise direct sales at a
competitive price. Welcome to visit our factory at any time.
