    Fireboard Woodworking Mdf Lipping Machine Automatic Linear Edge Banding Machine

    Ask Lasest Price
    Brand Name : HOLD
    Model Number : HD621JPUD
    Price : Negotiable
    Supply Ability : 10 Set / Month
    Delivery Time : 45 Days
    Certification : CE
    Payment Terms : LC/ TT
    • Product Details
    • Company Profile

    Fireboard Woodworking Mdf Lipping Machine Automatic Linear Edge Banding Machine

    Linear Edge Banding Machine HD621JPUD with PUR gluing pre-milling and corner rounding.


    Features:

    1. As we know, if using the EVA glue for the edge banding, it would have the glue line, especially for the light color panel. But with the PUR gluing unit, can improve this problem, just need a very thin glue coating, then the edge can be stick to the panel very well, and the glue line is thinner.

    2. PUR glue has the feature that if it was combined with the moisture in the air, it can't be melt again, So, it has very stable physical properties,

    3. If you looking for an edge bander for high-end products, this would be absolutely better choice for your products.

    4. Machine has equipped with pre-milling rough trimmer fine trimmer and corner rounding, suitable for all kinds of edge banding.


    Technical specifications:

    1. Model NO.: HD621JPUD
    2. Certification: CE
    3. Panel Thinkness: 10-60mm
    4. Min.length panel: 120mm
    5. Min.width panel: 60mm
    6. After-sales Service: 1 Y
    7. Tapethickness: 0.4-3mm
    8. Control system : LS -Korean
    9. Guide Rail:China
    10. Panelthickness:12-60mm
    11. Workpiecethickness:10-60mm
    12. Conveyor Motor: 2.2Kw
    13. Panel Preheating Power: 0.3 Kw
    14. Glue Melting Power: 1.5 Kw
    15. Panel Preheating Motor:0.3 Kw
    16. Packing :Plywood Box with Strength Film
    17: Overall size: 7200mm*900mm*1700mm
    18. Origin: GuandDong China
    19. HS Code: 8465940000

    More Details:


    Fireboard Woodworking Mdf Lipping Machine Automatic Linear Edge Banding MachineFireboard Woodworking Mdf Lipping Machine Automatic Linear Edge Banding MachineFireboard Woodworking Mdf Lipping Machine Automatic Linear Edge Banding Machine


    For understanding more about our machine, please check the below link to Youtube:


    Fireboard Woodworking Mdf Lipping Machine Automatic Linear Edge Banding Machine


    About our company


    One-stop solution for

    interior furniture equipment and wooden door equipment

    HOLD Machinery was founded in 2004, focusing on the development of a full range of furniture machinery equipment and wooden door machinery and equipment, providing furniture and wooden door enterprises with solutions for whole factory planning and automatical production lines, providing customers with excellent quality, efficient and stable products, and high-quality service.

    HOLD Machinery has served the majority of furniture and wooden door enterprises in more than 40 countries and regions around the world and has won wide admiration from customers.


    FAQ:

    1. Do you have the machine in stock?
    Sorry, we don't have the machine in stock, edge banding machine has many options such as voltage, speed, function, and so on, So it's hard to prepared samples.

    2. How long is your delivery time?
    For our standard model, the delivery time is around 1.5~2 months. For the customized model, the delivery time is around 2~3 months. It depends on the client's project and quantity.

    3. Do you have a factory?
    Yes, we have our own factory and we promise direct sales at a competitive price. Welcome to visit our factory at any time.
