    Pvc Veneer Melamine Door Lipping Machine Edge Banding Equipment High Speed

    Ask Lasest Price
    Brand Name : HOLD
    Model Number : HD661
    Price : Negotiable
    Supply Ability : 10 Set / Month
    Delivery Time : 45 Days
    Certification : CE
    Payment Terms : LC/ TT
    • Product Details
    • Company Profile

    Pvc Veneer Melamine Door Lipping Machine Edge Banding Equipment High Speed

    High Speed Edgebanding Machine HD661


    Features:

    1. Used for different plates: MDF, blockboard, particleboard, solid wood board, plywood, polymer plate, fireboard, etc.

    2. Banding edge for desks, cabinets, wardrobe, and straight-line furniture.

    3. Tape material can be PVC, melamine, veneer, etc.

    4. Can save lots of labor and cost, especially suitable for medium and large-scale users.

    5. Concentrated modern design for the automatic woodworking production line.


    Technical specifications:

    ModelHD661
    Panel Thickness10-60mm
    Edge Band Thickness0.3-3mm
    Panel Width≥80mm
    Panel Length≥100mm
    Feeding Speed14-20m/min
    Working Pressure0.6Mpa
    Voltage380V/50HZ/3PH
    Gluing Motor0.37KW/50HZ/1400RPM
    End Cutting Motor0.37KW * 2/200HZ/12000RPM
    Rough Trimming Motor0.55KW * 2/200HZ/12000RPM
    Fine Trimming Motor0.55KW * 2/200HZ/12000RPM
    Buffing Motor0.37KW * 2/50HZ/1400RPM
    Conveyor Motor2.2KW
    Glue Pot Heating Power1.5KW
    Assistant Heating Power0.3KW
    Lighting Power0.1KW
    Total Power13.58KW
    Dimension7170mm*900mm*1700mm


    More Details:


    Pvc Veneer Melamine Door Lipping Machine Edge Banding Equipment High SpeedPvc Veneer Melamine Door Lipping Machine Edge Banding Equipment High SpeedPvc Veneer Melamine Door Lipping Machine Edge Banding Equipment High SpeedPvc Veneer Melamine Door Lipping Machine Edge Banding Equipment High Speed


    Please log on to our website to watch more videos:


    Pvc Veneer Melamine Door Lipping Machine Edge Banding Equipment High Speed


    About our company


    One-stop solution for interior furniture equipment and wooden door equipment

    HOLD Machinery was founded in 2004, focusing on the development of a full range of furniture machinery equipment and wooden door machinery and equipment, providing furniture and wooden door enterprises with solutions for whole factory planning and automatical production lines, providing customers with excellent quality, efficient and stable products, and high-quality service.

    HOLD Machinery has served the majority of furniture and wooden door enterprises in more than 40 countries and regions around the world and has won wide admiration from customers.


    FAQ:

    1. Do you have the machine in stock?
    Sorry, we don't have the machine in stock, edge banding machine has many options such as voltage, speed, function, and so on, So it's hard to prepared samples.

    2. How long is your delivery time?
    For our standard model, the delivery time is around 1.5~2 months. For the customized model, the delivery time is around 2~3 months. It depends on the client's project and quantity.

    3. Do you have a factory?
    Yes, we have our own factory and we promise direct sales at a competitive price. Welcome to visit our factory at any time.
